- Smart NVR64ch/128ch GSA-64NVR-P/GSA-128NVR-P1
Feature：
•Support 4/8/16ch full 4k video real-time access, 1U, 2 SATA ports
•Support H.265/H.264 stream, embedded Linux operating
•Support video playback, remote monitoring and backup.
•Support preview and playback with 12 times electronic amplification.
•Standard ONVIF, RTSP, GB28181 protocol.
•Support DDNS, EMAIL, UPNP, NTP, etc.
•Support Web, mobile monitoring, PC client,CMS software.
•Support UMeye P2P.
•Support channel grouping, preview cycle.
•Support 4/8/16ch sub stream video synchronous playback and multi channel synchronous playback.
• Support dual password authentication.
| Technical specification | ||
| Model | GSA-64NVR-P | GSA-128NVR-P1 |
| Operating System | Embedded Linux operating system | |
| Video | ||
| Network video input | 64ch 4K/5MP/3MP/1080p/960p/720p input | 128ch 4K/5MP/3MP/1080p/960p/720p input |
| Network video output | 2*VGA/2* HDMI， | |
| Video bit rate | 16-8000Kbps | |
| Image preview | 1/4/6/8/9/16/25/36 channel | 1/4/6/8/9/16/25/36/64 channel |
| Video compression | H.265/H.264/MJPEG | |
| Capture mode | Schedule/Manual, JPEG format | |
| Audio | ||
| Audio | 1ch audio input and 1ch output | |
| Audio compression | G.711A | |
| Storage | ||
| HDD port | 16 SATA ports, 2 E-SATA | |
| Raid mode | Raid0, Raid1, Raid5, Raid6, Raid10 | |
| Capacity | Support 6TB HDD | |
| Alarm | ||
| Motion detection | Support image set to 396 (22*18) detection areas, multistage sensitivity | |
| Smart detection | Motion detection, video miss, video occlusion, occlusion alarm | |
| Alarm | 16ch input，8ch output | |
| Network management | ||
| Network protocol | TCP/IP,HTTP,DDNS,SMTP(SSL),DHCP,PPPOE,UPNP,NTP | |
| Compliance protocol | ONVIF, RTSP, GB28181 | |
| Remote application | WEB(IE, Chrome, Firefox, Safiri), IOS, Android Mobile monitor | |
| Smart analysis | Target count, Item detection, Area detection, Virtual cordon, Scene | |
| transformation | ||
| Others | Dual password authentication | |
| Video management | ||
| Record mode | Manual/Schedule record, Motion alarm record, Motion alarm Snap, link | |
| down record | ||
| Resolution | 128ch 4K/5MP/3MP/1080p/960p/720p | |
| Broadband access | 640Mbps | |
| Record frame rate | 1-30fps | |
| Video query | Time, Date, Event, Channel, Exact Search (accurate to second） | |
| Record storage path | Local, Network, NAS, IPSAN | |
| Playback&Backup | ||
| Playback mode | Regular playback, instant replay, event playback, external file playback | |
| 4ch 4K/5MP | ||
| Playback capability | 9ch 3MP | |
| 16ch 1080p/960p/720p | ||
| Play, Stop, Rewind, Next File, Previous File, Next Camera, Previous | ||
| Playback operations | Camera, Fast play, Slow play, Single frame, Backup, Screenshot, Full screen | |
| selection | ||
| Backup mode | Removable HDD, USB flash disk, Network backup | |
| External ports | ||
| Network port | 2 RJ45 Ports (100M/1000M Ethernet port ) | |
| USB port | 2PCS 2.0 USB port, 1PCS 3.0 USB port | |
| RS485 port | Support | |
| Audio port | 1PCS input, 2PCS output | |
| General | ||
| Power supply | AC100～240V，47Hz～63Hz | |
| Power consumption | ≤ 50W (Without HDD) | |
| Storage condition | -10°C ~ 55°C / 10﹪-90﹪RH | |
| Dimensions | W430mm×D483mm×H143mm | |
| 18.5KG | ||
